IntiGROUND

TECHNICAL CHARACTERISTICS

• Light source:

  Nichia (Japan), Cree (USA) LEDs

• Light color:

  white (3000 К, 4000 К, 5000 К), RGB

• Optics:

  10°, 30°, 10х50°, 60°, 80°

• Luminous flux:

  up to 2450 lm

• Power input:

  25, 28 W

• Power factor Cos φ:

  >0,9

• Voltage:

  90-264 V AC

• Protection class:

  IP67

• Operation temperature:

  -40°С ... +45°С for standard model, -40°С ... +55°С for tropic edition

• Lifespan:

  no less than 50000 hours

• Control:

  for white - not available, for RGB - available via DMX-512

• Dimensions:

  318x318x140 mm

• Weight:

  7 kg

• Customization:

  Control/power cables of any length, Control: PWM

• Mounting:

  Build into the ground or concrete with different surfaces (asphalt, paving slab, facing stone etc.)

SPECIFIC TECHNICAL FEATURES

decorative frame: polished stainless steel

Quickly replaceable in case of prolonged luminaire operation. The frame together with the molded rubber sealer ensure reliable sealing of the luminaire and the IP67 protection grade.

hexagonal LED placement

With color versions, allows for obtaining any color without undesirable light effects.

136 mm embedding depth

Substantially simplifies installation of the unit.

built-in adjustment mechanism (up to 15 degrees of adjustment)

Allows for easy aiming of the beam to a required spot when mounting or commissioning.

•

  decorative frame: polished stainless steel

  Quickly replaceable in case of prolonged luminaire operation. The frame together with the molded rubber sealer ensure reliable sealing of the luminaire and the IP67 protection grade.

•

  hexagonal LED placement

  With color versions, allows for obtaining any color without undesirable light effects.

•

  136 mm embedding depth

  Substantially simplifies installation of the unit.

•

  built-in adjustment mechanism (up to 15 degrees of adjustment)

  Allows for easy aiming of the beam to a required spot when mounting or commissioning.
